20-150 T/D complete set of maize milling machine

　　20-150 T/D complete set of maize milling machine adopts dry peeling and degerming technology, it can produce different sizes of corn grits and flour at the same time.

　　Corn grits size can be customized as per customer’s need in order to meet various needs such as brewery, snack food, glucose, and sugarhouse. Thanks for the dry peeling and degerming technology, husks and germs collected at the end don’t need to be dried before used for animal feed.

　　This maize milling machine is hot sale in kenya, and it is used for the hulling, making grits and milling of corn. After the hulling treatment of the product, the net kernels were sent to the gritting and milling chamber. Then through the process of crushing and grinding, high quality grits and flour were produced

　　This series of corn product line build up with: corn process equipment (e.g.: corn cleaning, corn huller, corn polisher, new super fine corn grits machine, corn flour milling machine and more) and foodstuff process general equipment (e.g.: hoist, density corn destoner, plansifter, miller, flour cleaner).

　　This complete set of maize milling machine can produce low fat corn grits, corm germ, corn flour and corn peel with different size at the same time. The throughput of the set varies from 20 tons to 150 tons per 24 hours. The whole assembly line consists of grain cleaning, maize peeling, maize milling and maize flour packing parts.

　　Features of maize milling machine

　　1. It can finish cleaning, peeling, removing embryo, radices and black cord, crushing, grit getting, polishing, grading, selecting flour in one time.

　　2. Beautiful appearance, easy operation, reliable performance, and energy saving.

　　3. It's suitable for wet and drying peeling.

　　4. It has wind webdust control system, stepless smashing system, electric currency display system, and more

　　5. It’s suitable for kinds of corn, and this machine had exported to many countries successfully.

　　6. Total quality product rate: 70~80% with output:

　　(1) Corn 20~30%;

　　(2) Big corn grits 8-10%

　　(3) Small corn grits 27~35%;

　　(4) Corn germs 5~7%.

　　7.Total byproduct rate: 25~32%, grain loss 1%. and  feed flour 25~32%; grain loss1%.

　　8. Quality standard for finished products:

　　(1) Corn flour: greys ≤0.65%, magnetic metal ≤0.03%, sand and stones ≤0.02%, moisture in corn flour 12~12.5%;

　　(2) Germ purity over 85%;

　　(3) No special requirements for feed flour.

　　9.Moisture in raw materials is controlled within 15%; corn volume weight 700~750kg/m³.

　　Key Specifications/ Special Features:

　　♦ Turnkey project of maize flour milling machinery.

　　♦ Advanced technology support and customized design

　　♦ Thorough crafts and rational allocation.

　　♦ Low power consumption.

　　♦ Perfect after-sales service.

　　♦ One year guarantee.

　　♦ One year spare parts for free

　　♦ Long lifetime due to imported spare parts.
